| Tipe Mesin | 4 Langkah, DOHC 4 Katup |
| Kapasitas Mesin | 149,16 cc |
| Sistem Suplai Bahan Bakar | PGM-FI (Programmed Fuel Injection) |
| Diameter X Langkah | 57,3 x 57,843 mm |
| Tipe Tranmisi | Manual, 6 Kecepatan |
| Perbandingan Kompresi | 11,3 : 1 |
| Daya Maksimum | 12,4 kW (16,9 PS) / 9.000 rpm |
| Torsi Maksimum | 13,8 Nm (1,41 kgf.m) / 7.000 rpm |
| Tipe Starter | Electric |
| Tipe Kopling | Multiple Wet Clutch with Coil Spring |
| Sistem Pendingin | Liquid Cooled |
| Pola Perpindahan Gigi | 1 - N - 2 - 3 - 4 - 5 - 6 |
| Tipe Minyak Pelumas | Wet |
| Tipe Rangka | Diamond (Truss) Frame |
| Tipe Suspensi Depan | Showa 37mm Inverted Telescopic |
| Tipe Suspensi Belakang | Lengan Ayun dengan suspensi tunggal (Sistem Pro-Link) |
| Ukuran Ban Depan | 100/80-17M/C 52P, Tubeless |
| Ukuran Ban Belakang | 130/70-17M/C 62P, Tubeless |
| Tipe Rem Depan | Wavy Disc Brake |
| Tipe Rem Belakang | Wavy Disc Brake |
| Panjang X Lebar X Tinggi | 2.024 x 796 x 1.083 mm |
| Tinggi Tempat Duduk | 795 mm |
| Jarak Sumbu Roda | 1.298 mm |
| Jarak Terendah Ke Tanah | 164 mm |
| Berat Kosong (Curb Weight) | 134 (Standard) & 135 kg (Special Edition) |
| Kapasitas Tangki Bahan Bakar | 12 Liter |
| Kapasitas Minyak Pelumas | 1,1 Liter (Penggantian Periodik) |
| Tipe Battery/Aki | MF-Wet 12V-5Ah |
| Sistem Pengapian | Full Transisterized |
| Tipe Busi | NGK MR9C-9N atau DENSO U27EPR-N9 |
