| Tipe Mesin | 4 – Langkah, SOHC, eSP |
| Sistem Suplai Bahan Bakar | PGM – FI ( Programmed Fuel Injection ) |
| Diameter X Langkah | 47,0 x 63,1 mm |
| Tipe Tranmisi | Automatic, V-Matic |
| Rasio Kompresi | 10,0 : 1 |
| Daya Maksimum | 6,6 kW ( 9,0 PS ) / 7.500 rpm |
| Torsi Maksimum | 9,3 Nm ( 0,95 kgf.m ) / 5.500 rpm |
| Tipe Starter | Elektrik dan Kick Starter |
| Tipe Kopling | Automatic Centrifugal Clutch Dry Type |
| Tipe Rangka | Underbone – eSAF ( Enhanced Smart Architecture Frame ) |
| Tipe Suspensi Depan | Telescopic |
| Tipe Suspensi Belakang | Swing Arm dengan Suspensi Tunggal |
| Ukuran Ban Depan | 100/90 – 12 59J (Tubeless) |
| Ukuran Ban Belakang | 110/90 – 12 64J (Tubeless) |
| Rem Depan | Cakram Hidrolik Piston Tunggal |
| Rem Belakang | Tromol |
| Sistem Pengereman | Combi Brake System |
| Panjang X Lebar X Tinggi | 1.862 x 694 x 1.061 mm |
| Tinggi Tempat Duduk | 744 mm |
| Jarak Sumbu Roda | 1.251 mm |
| Jarak Terendah Ke Tanah | 150 mm |
| Curb Weight | 92 kg (Tipe CBS) 93kg (Tipe CBS - ISS) |
| Kapasitas Tangki Bahan Bakar | 4,2 L |
| Kapasitas Minyak Pelumas | 0,65 L ( Penggantian Periodik ) |
| Tipe Baterai Atau Aki | MF 12 V – 3Ah ( Tipe CBS ) , MF 12 V – 5 Ah ( Tipe CBS – ISS ) |
| Sistem Pengapian | Full Transisterized |
| Tipe Busi | NGK MR9C-9N |
Please do not hesitate to contact us if you would like more information regarding prices and availability
